On a local area network (LAN), network devices will traditionally connect to each other using some type of cabling. Even on LANs that have a wireless segment, the access points will be connected to the core network using a physical network connection. Over the years, different types of networks have used a number of different types of cables.

As layer 2 technologies have developed, so has network cabling. All cables used in the computer networking industry, past and present, can be categorized into three distinct groups: coaxial (coax), twisted pair, and fiber-optic.

Coaxial Cable

Coaxial (coax) cable has been around for many years and is very commonly used in the video industry. Coax was also used on early networks but is no longer being widely implemented for network communication. Coax is a very sturdy cable and contains a central conductor wire surrounded by an insulating material, which in turn is surrounded by a braided metal shield. There are few variations of this cable some with thicker copper cores than others.

The differences in the type of coax that you use may allow you to use them in different capacities, such as in running longer distance cabling. Coax wire was used on the original Ethernet networks implemented with a Bus Topology.

Computer networks that use coax cable will use a thicker type of coax known as RG-6 (75 Ohms). For television and video transmissions, RG-59 is was historically used. It is now more common to find both networking and video applications to use RG-6.

3E123Ec5059A463E9Ad66695Fa63Dddb

Coaxial cable shields data transmissions from electro-magnetic interference (EMI). Electrical devices produce EMI. When a metal wire encounters these magnetic fields, an electrical current is generated along the wire. This electric current on your network wire will cause major issues.

The outer mesh layer of coaxial cable shields the center from the unwanted interference. Even though the wire is protected, you want to make sure you keep your wires away from electrical devices.

Twisted Pair Cable

By far, the most common type of cabling used on modern networks today consists of twisted pair cabling. Twisted pair cabling is a type of cabling, that contains individual stands of copper cables bundled together into a common jacket. Individual pairs of cables are twisted together.

You will find two types of twisted-pair cabling on modern networks: shielded twisted pair (STP) and unshielded twisted pair (UTP). The primary reason for twisted pair cabling is to reduce interference, also known as crosstalk. As mentioned in the Coaxial section, cabling is susceptible to magnetic interference. The twists in UTP and STP cables are used to mitigate the crosstalk problem. The more twists, the less crosstalk.

E76A1E878Cf54E20Aadc03C72830Abf8

STP, or Shielded twisted pair, as its name implies, consists of twisted pairs of wires surrounded by shielding to protect them from EMI. STP is not generally implemented on networks unless it is absolutely necessary. It is more costly than UTP cabling and in many cases, to mitigate EMI, you simply just need to run the UTP cabling away from electrical devices that produce magnetic interference.

UTP consists of twisted pairs of wires surrounded by a plastic jacket. This jacket does not provide any protection from EMI, so as mentioned earlier, you must keep the cable away from electrical interference.

UTP cabling has a number of variations, such as the number of twists per foot. The more twists, the faster you can move data on the wire. The cabling industry has developed a variety of grades called category (CAT) ratings. CAT ratings are rated in megahertz (MHz)

CategoryMax FrequencyMax Bandwidth
CAT 11 MHz
CAT 24 MHz4 Mbps
CAT 316 MHz16 Mbs
CAT 420 MHz20 Mbs
CAT 5100 MHz100 Mbs
CAT 5e100 MHz1 Gbs
CAT 6250 MHz10 Gbs

Fiber Optic Cable

Fiber optic cable has one main advantage over copper cabling. It transmits light rather than electricity. Therefore, fiber optic cabling is not susceptible to EMI. While a copper cable is unable to carry a signal more than a few hundred meters, fiber optic cabling can be run for distances up to tens of kilometers.

5Eb20F28Db5B485Cb3Bd3B922Eea404E

A fiber optic cable generally has four components: the core (glass fiber), the cladding (reflects light down the fiber), buffer material for strength, and the insulating jacket for protection. Fiber optic cabling is manufactured with different diameters of core and cladding.

The most common fiber optic cable size is 62.5/125 μm. Fiber optic cable will either be multimode or single mode cable. Multimode fiber is used with LEDs to transmit data, while single mode fiber is used with Lasers. Single mode cable is generally more expensive and can be used for longer distances when compared to multimode fiber cable.
