AJAX XMLHttpRequest readyState

In this article, we are going to look at the readyState property in more detail. When a request is sent to a web server, the server processes the request and sends data back to the browser. Before the browser takes action on the response, you want to make sure that the browser has finished receiving the response from a valid page on a web server.

We depend on the onreadystatechange event which is triggered every time the readyState changes. The readyState property contains the status of the XMLHttpRequest. We simply need to check the readyState value and status prior to taking action on the data that was received.

HTML Example

<!DOCTYPE html>
<html>
<head>
    <script type="text/javascript">
        function loadAjax() {
            var xhr = false;
            if (window.XMLHttpRequest) {
                // IE7+, Firefox, Chrome, Opera, Safari
                xhr = new XMLHttpRequest();
            }
            else {
                // IE5/IE6
                xhr = new ActiveXObject("Microsoft.XMLHTTP");
            }
            if (xhr) {
                xhr.onreadystatechange = function () {
                    if (xhr.readyState == 4 && xhr.status == 200) {
                        document.getElementById("div1").innerHTML = xhr.responseText;
                    }
                }
                xhr.open("GET", "/demo/ajax_load.txt", true);
                xhr.send(null);
            }
        }
    </script>
</head>
<body>
    <img id="img1" onclick="loadAjax()" src="go.png" /> ;
    <div id="div1"> <!-- Some Content --> </div>
</body>
</html>

XMLHTTPRequest Properties

PropertyDescription
onreadystatechangeFunction to be called when the readyState property changes
readyStateHolds the status of the XMLHttpRequest. Values from 04
statusReturns the status-number. 200, 404
statusTextReturns the status-text: Ok, Not Found

readyState Status

  • 0 – request not initialized
  • 1 – server connection established
  • 2 – request received
  • 3 – processing request
  • 4 – request completed and response is ready

To ensure that we do not take action on the data that is received from the web server until it has been completed, we simply check the status of the readyState property when the onreadystatechange event changes. When the readyState value is 4 and status value is 200, the response is ready.

xhr.onreadystatechange = function () {
    if (xhr.readyState == 4 && xhr.status == 200) {
        document.getElementById("div1").innerHTML = xhr.responseText;
    }
}
